2024 Bmw X3 Bolt Pattern 5x112

Wheel and tire specifications for the Bmw X3 2024. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Bmw X3
✨ AI-generated image for reference only

Vehicle Info

Bmw X3 2024
Generation
G01 LCI (2021–2024)
Trim
Standard Trim
Modification
AI Verified Specs
Note

Wheel and tire specifications are consistent across sDrive30i, xDrive30i, and M40i trims, with variations primarily in wheel diameter, width, and offset based on packages and options. The X3 M (F97) has distinct wheel and tire specifications.

Wheel Specifications

Bolt pattern
5x112
Center bore
66.6 mm
Thread size
M14 x 1.25
Torque
140 Nm
Lugs
5
Fastener type
lug bolts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
18x719x7.520x820x9.5

Wheel & tire specs guide — Bmw X3 2024

The 2024 Bmw X3 features a 5x112 bolt pattern, meaning it has 5 lug nuts arranged on a 112mm diameter circle, the center bore measures 66.6mm, the wheels are secured with M14 x 1.25 threaded lug nuts torqued to 140 Nm.

Wheel and tire specifications are consistent across sDrive30i, xDrive30i, and M40i trims, with variations primarily in wheel diameter, width, and offset based on packages and options. The X3 M (F97) has distinct wheel and tire specifications.

From the factory, the Bmw X3 2024 is offered with OEM tires in the following sizes: 225/60R18, 245/50R19, 245/45R20, 275/40R20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
