2017 Chevrolet Equinox Bolt Pattern 5x120

Wheel and tire specifications for the Chevrolet Equinox 2017. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

✨ AI-generated image for reference only

Vehicle Info

Chevrolet Equinox 2017

Generation

2nd Generation (2010–2017)

Trim

Standard Trim

Modification

AI Verified Specs

Note

This data is for the 2nd-generation 2017 Chevrolet Equinox (USDM). Some databases incorrectly list 3rd-generation specs (5x115 PCD) for 2017 models. Drivetrain (FWD/AWD) and trim levels (L, LS, LT, LTZ/Premier) do not change PCD, bore, or lug specifications; only tire and wheel sizes vary. Verify bolt pattern and torque with owner's manual or dealer due to conflicting information for 2017 models.

Wheel Specifications

Bolt pattern

5x120

Center bore

66.9 mm

Thread size

M14 x 1.5

Torque

190 Nm

Lugs

Fastener type

lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes

17x718x719x7.5

Wheel & tire specs guide — Chevrolet Equinox 2017

The 2017 Chevrolet Equinox features a 5x120 bolt pattern, meaning it has 5 lug nuts arranged on a 120mm diameter circle, the center bore measures 66.9mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 190 Nm.

From the factory, the Chevrolet Equinox 2017 is offered with OEM tires in the following sizes: 225/65R17, 225/60R18, 235/50R19. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
