2017 Chevrolet Tahoe Bolt Pattern 6x139.7

Wheel and tire specifications for the Chevrolet Tahoe 2017. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Chevrolet Tahoe
✨ AI-generated image for reference only

Vehicle Info

Chevrolet Tahoe 2017
Generation
K2XX (2015–2020)
Trim
Standard Trim
Modification
AI Verified Specs
Note

All hardware specifications (PCD, center bore, lug count, thread, torque) are the same across 2WD and 4WD variants and across LS, LT, and Premier trims. Wheel and tire sizes vary by trim and optional packages.

Wheel Specifications

Bolt pattern
6x139.7
Center bore
78.1 mm
Thread size
M14 x 1.5
Torque
190 Nm
Lugs
6
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
18x8.520x9.022x9.0

Wheel & tire specs guide — Chevrolet Tahoe 2017

The 2017 Chevrolet Tahoe features a 6x139.7 bolt pattern, meaning it has 6 lug nuts arranged on a 139.7mm diameter circle, the center bore measures 78.1mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 190 Nm.

All hardware specifications (PCD, center bore, lug count, thread, torque) are the same across 2WD and 4WD variants and across LS, LT, and Premier trims. Wheel and tire sizes vary by trim and optional packages.

From the factory, the Chevrolet Tahoe 2017 is offered with OEM tires in the following sizes: 265/65R18, 275/55R20, 285/45R22. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
