2019 Ford Explorer Bolt Pattern 5x114.3

Wheel and tire specifications for the Ford Explorer 2019. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

✨ AI-generated image for reference only

Vehicle Info

Ford Explorer 2019

Generation

5th Generation (2011–2019)

Trim

Standard Trim

Modification

AI Verified Specs

Note

The 5th generation Explorer (U502) ran from 2011-2019. All trims and drivetrain variants (FWD/4WD) share the same bolt pattern, center bore, lug count, thread size, and torque specifications. Wheel and tire dimensions vary by trim and optional packages.

Wheel Specifications

Bolt pattern

5x114.3

Center bore

63.4 mm

Thread size

M14 x 1.5

Torque

135 Nm

Lugs

Fastener type

lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes

18x7.518x8.020x8.520x9.0

Wheel & tire specs guide — Ford Explorer 2019

The 2019 Ford Explorer features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 63.4mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 135 Nm.

From the factory, the Ford Explorer 2019 is offered with OEM tires in the following sizes: 245/60R18, 255/50R20, 265/45ZR20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
