2015 Ford F 150 Bolt Pattern 6x135

Wheel & tire specs guide — Ford F 150 2015

The 2015 Ford F 150 features a 6x135 bolt pattern, meaning it has 6 lug nuts arranged on a 135mm diameter circle, the center bore measures 87.1mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 204 Nm.

All 2WD and 4WD variants, and all trims (XL, XLT, Lariat, King Ranch, Platinum, Limited), share the same core wheel attachment specifications (bolt pattern, center bore, stud count, lug thread/torque). Variations occur in OEM tire sizes, wheel diameters/widths, and offsets, which are all within a tight positive range. The most commonly cited OEM offset for 2015 F-150 wheels is +44 mm, especially for 17" wheels. Some trims or larger wheel options may use ~+30 mm offset.

From the factory, the Ford F 150 2015 is offered with OEM tires in the following sizes: 245/70R17, 265/70R17, 265/70R18, 275/55R20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
