2025 Gmc Sierra 1500 Bolt Pattern 6x139.7

Wheel and tire specifications for the Gmc Sierra 1500 2025. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Gmc Sierra 1500
✨ AI-generated image for reference only

Vehicle Info

Gmc Sierra 1500 2025
Generation
5th Generation (2019–2026)
Trim
Standard Trim
Modification
AI Verified Specs
Note

Bolt pattern, hub bore, stud size, lug count, and basic offset range are the same across all trims and drivetrains (2WD/4WD). Differences are mainly in wheel diameter, width, and tire size.

Wheel Specifications

Bolt pattern
6x139.7
Center bore
78.1 mm
Thread size
M14 x 1.5
Torque
190 Nm
Lugs
6
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
17x818x8.520x922x9

Wheel & tire specs guide — Gmc Sierra 1500 2025

The 2025 Gmc Sierra 1500 features a 6x139.7 bolt pattern, meaning it has 6 lug nuts arranged on a 139.7mm diameter circle, the center bore measures 78.1mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 190 Nm.

Bolt pattern, hub bore, stud size, lug count, and basic offset range are the same across all trims and drivetrains (2WD/4WD). Differences are mainly in wheel diameter, width, and tire size.

From the factory, the Gmc Sierra 1500 2025 is offered with OEM tires in the following sizes: 255/70R17, 265/70R17, 265/65R18, 275/65R18, 275/70R18, 265/60R20, 275/60R20, 275/50R22. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
