2005 Honda Cr V Bolt Pattern 5x114.3

Wheel and tire specifications for the Honda Cr V 2005. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Honda Cr V
✨ AI-generated image for reference only

Vehicle Info

Honda Cr V 2005
Generation
2nd Generation (2002–2006)
Trim
Standard Trim
Modification
AI Verified Specs
Note

OEM tire sizes for 2005 include 215/65R16 on 6.5Jx16 ET50 and 205/65R16 on 6Jx16 ET50. No differences in OEM tire size or wheel diameter between trims or 2WD/4WD in US market for 2005. LX, EX, and SE trims all use the same size.

Wheel Specifications

Bolt pattern
5x114.3
Center bore
64.1 mm
Thread size
M12 x 1.5
Torque
108 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
16x6.516x6

Wheel & tire specs guide — Honda Cr V 2005

The 2005 Honda Cr V features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 64.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 108 Nm.

OEM tire sizes for 2005 include 215/65R16 on 6.5Jx16 ET50 and 205/65R16 on 6Jx16 ET50. No differences in OEM tire size or wheel diameter between trims or 2WD/4WD in US market for 2005. LX, EX, and SE trims all use the same size.

From the factory, the Honda Cr V 2005 is offered with OEM tires in the following sizes: 215/65R16, 205/65R16. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
