2021 Hyundai Palisade Bolt Pattern 5x114.3

Wheel and tire specifications for the Hyundai Palisade 2021. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

✨ AI-generated image for reference only

Vehicle Info

Hyundai Palisade 2021

Generation

1st Generation (2020–2022)

Trim

Standard Trim

Modification

AI Verified Specs

Note

All trims (SE, SEL, Limited, Calligraphy) are available in FWD and AWD variants. Wheel hardware specifications (PCD, center bore, thread size, number of lugs) do not change between trims or drivetrains. OEM wheel offset is nominally +49.5 mm, with an acceptable range of +47.5 to +51.5 mm for stock wheels. The vehicle uses a direct TPMS system with in-wheel pressure sensors.

Wheel Specifications

Bolt pattern

5x114.3

Center bore

67.1 mm

Thread size

M12 x 1.5

Torque

107–127 Nm

Lugs

Fastener type

lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes

18x7.520x7.5

Wheel & tire specs guide — Hyundai Palisade 2021

The 2021 Hyundai Palisade features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 67.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 107–127 Nm.

From the factory, the Hyundai Palisade 2021 is offered with OEM tires in the following sizes: 245/60R18, 245/50R20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
