2018 Hyundai Santa Fe Bolt Pattern 5x114.3

Wheel and tire specifications for the Hyundai Santa Fe 2018. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

✨ AI-generated image for reference only

Vehicle Info

Hyundai Santa Fe 2018

Generation

3rd Generation (DM) (2012–2018)

Trim

Standard Trim

Modification

AI Verified Specs

Note

Wheel hardware specs (PCD, center bore, threads, lug count) are constant across all 2018 Santa Fe 3-row trims and drivetrains (FWD/AWD). Tire and wheel dimensions vary by trim level. Some wider tire options (255-width) are more typical in non-U.S. markets or specific packages.

Wheel Specifications

Bolt pattern

5x114.3

Center bore

67.1 mm

Thread size

M12 x 1.5

Torque

107–127 Nm

Lugs

Fastener type

lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes

17x718x7.519x7.520x?

Wheel & tire specs guide — Hyundai Santa Fe 2018

The 2018 Hyundai Santa Fe features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 67.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 107–127 Nm.

From the factory, the Hyundai Santa Fe 2018 is offered with OEM tires in the following sizes: 235/65R17, 235/60R18, 235/55R19, 245/60R17, 255/60R17, 245/55R18, 255/55R18, 245/50R19, 255/50R19, 245/45R20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
