2024 Hyundai Santa Fe Bolt Pattern 5x114.3

Wheel and tire specifications for the Hyundai Santa Fe 2024. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Hyundai Santa Fe
✨ AI-generated image for reference only

Vehicle Info

Hyundai Santa Fe 2024
Generation
5th Generation (2024–present)
Trim
Standard Trim
Modification
AI Verified Specs
Note

Bolt pattern, hub bore, lug count, and thread size are the same across FWD vs AWD, Gas (ICE) vs Hybrid (HEV), and all trims. Differences are mainly tire/wheel size and tire brand specification.

Wheel Specifications

Bolt pattern
5x114.3
Center bore
67.1 mm
Thread size
M12 x 1.5
Torque
107–127 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
18x7.520x8.521x8.5

Wheel & tire specs guide — Hyundai Santa Fe 2024

The 2024 Hyundai Santa Fe features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 67.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 107–127 Nm.

Bolt pattern, hub bore, lug count, and thread size are the same across FWD vs AWD, Gas (ICE) vs Hybrid (HEV), and all trims. Differences are mainly tire/wheel size and tire brand specification.

From the factory, the Hyundai Santa Fe 2024 is offered with OEM tires in the following sizes: 235/60R18, 255/45R20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
