2025 Hyundai Tucson L Bolt Pattern 5x114.3

Wheel and tire specifications for the Hyundai Tucson L 2025. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

✨ AI-generated image for reference only

Vehicle Info

Hyundai Tucson L 2025

Generation

4th Generation (NX4) (2021–present)

Trim

Standard Trim

Modification

AI Verified Specs

Note

2WD/FWD and HTRAC AWD versions use the same fundamental wheel hardware (PCD, center bore, fasteners). Differences between trims are primarily factory tire and wheel diameter. The N Line is also listed with 235/55 R19 on a 7.5J × 19 wheel.

Wheel Specifications

Bolt pattern

5x114.3

Center bore

67.1 mm

Thread size

M12 x 1.5

Torque

107–127 Nm

Lugs

Fastener type

lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes

17x7.0J18x7.5J19x7.5J

Wheel & tire specs guide — Hyundai Tucson L 2025

The 2025 Hyundai Tucson L features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 67.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 107–127 Nm.

From the factory, the Hyundai Tucson L 2025 is offered with OEM tires in the following sizes: 235/65R17, 235/60R18, 235/55R19. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
