2014 Isuzu Pickup Bolt Pattern 6x139.7

Wheel and tire specifications for the Isuzu Pickup 2014. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Isuzu Pickup
✨ AI-generated image for reference only

Vehicle Info

Isuzu Pickup 2014
Generation
2nd Generation (RT50/RT) (2011–2019)
Trim
D-Max RT50/RT
Modification
AI Verified Specs
Note

This vehicle was not sold in the USDM. Specs are for the global market 2014 Isuzu D-Max RT50/RT. Multiple trims and drive types (2WD/4WD) exist, sharing the same bolt pattern and center bore but with varying wheel/tire sizes.

Wheel Specifications

Bolt pattern
6x139.7
Center bore
100.5 mm
Thread size
M12 x 1.5
Torque
118 Nm
Lugs
6
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
6.5Jx156.5Jx167Jx16

Wheel & tire specs guide — Isuzu Pickup 2014

The 2014 Isuzu Pickup features a 6x139.7 bolt pattern, meaning it has 6 lug nuts arranged on a 139.7mm diameter circle, the center bore measures 100.5mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 118 Nm.

This vehicle was not sold in the USDM. Specs are for the global market 2014 Isuzu D-Max RT50/RT. Multiple trims and drive types (2WD/4WD) exist, sharing the same bolt pattern and center bore but with varying wheel/tire sizes.

From the factory, the Isuzu Pickup 2014 is offered with OEM tires in the following sizes: LT215/70R15, LT205R16. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
