2011 Kia Sportage Bolt Pattern 5x114.3

Wheel and tire specifications for the Kia Sportage 2011. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Kia Sportage
✨ AI-generated image for reference only

Vehicle Info

Kia Sportage 2011
Generation
Third Generation (SL) (2011–2013)
Trim
Standard Trim
Modification
AI Verified Specs
Note

All trims (Base, LX, EX, SX) were available with FWD and optional AWD. Tire and wheel specifications primarily differ by trim level and optional packages, not by drivetrain.

Wheel Specifications

Bolt pattern
5x114.3
Center bore
67.1 mm
Thread size
M12 x 1.5
Torque
88–107 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
16x6.517x718x7

Wheel & tire specs guide — Kia Sportage 2011

The 2011 Kia Sportage features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 67.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 88–107 Nm.

All trims (Base, LX, EX, SX) were available with FWD and optional AWD. Tire and wheel specifications primarily differ by trim level and optional packages, not by drivetrain.

From the factory, the Kia Sportage 2011 is offered with OEM tires in the following sizes: 215/70R16, 225/60R17, 235/55R18. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
