2016 Lexus Nx Bolt Pattern 5x114.3

Wheel and tire specifications for the Lexus Nx 2016. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Lexus Nx
✨ AI-generated image for reference only

Vehicle Info

Lexus Nx 2016
Generation
AZ10 (2014–2021)
Trim
Standard Trim
Modification
AI Verified Specs
Note

All NX 200t (FWD/AWD) and NX 300h share the same PCD, hub bore, stud size, and TPMS configuration. Differences are wheel/tire size by trim (base vs F Sport vs Luxury) and market, not hardware. OEM tire sizes for USDM 2016 NX include 225/65R17, 225/60R18, and 235/55R18 (primarily for F Sport).

Wheel Specifications

Bolt pattern
5x114.3
Center bore
60.1 mm
Thread size
M12 x 1.5
Torque
103 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
17x718x7.519x7.519x820x8

Wheel & tire specs guide — Lexus Nx 2016

The 2016 Lexus Nx features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 60.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 103 Nm.

All NX 200t (FWD/AWD) and NX 300h share the same PCD, hub bore, stud size, and TPMS configuration. Differences are wheel/tire size by trim (base vs F Sport vs Luxury) and market, not hardware. OEM tire sizes for USDM 2016 NX include 225/65R17, 225/60R18, and 235/55R18 (primarily for F Sport).

From the factory, the Lexus Nx 2016 is offered with OEM tires in the following sizes: 225/65R17, 225/60R18, 235/55R18, 235/50R19, 245/45R19, 245/40R20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
