2018 Lexus Nx Bolt Pattern 5x114.3

Wheel and tire specifications for the Lexus Nx 2018. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Lexus Nx
✨ AI-generated image for reference only

Vehicle Info

Lexus Nx 2018
Generation
First Generation (2015–2021)
Trim
NX 300 / NX 300h
Modification
AI Verified Specs
Note

No differences in bolt pattern, center bore, or lug thread between 2WD and AWD variants. Differences are in tire size and wheel package availability.

Wheel Specifications

Bolt pattern
5x114.3
Center bore
60.1 mm
Thread size
M12 x 1.5
Torque
103 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
17x718x7.5

Wheel & tire specs guide — Lexus Nx 2018

The 2018 Lexus Nx features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 60.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 103 Nm.

No differences in bolt pattern, center bore, or lug thread between 2WD and AWD variants. Differences are in tire size and wheel package availability.

From the factory, the Lexus Nx 2018 is offered with OEM tires in the following sizes: 225/65R17, 225/60R18, 235/55R18. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
