2022 Lexus Nx Bolt Pattern 5x114.3

Wheel and tire specifications for the Lexus Nx 2022. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Lexus Nx
✨ AI-generated image for reference only

Vehicle Info

Lexus Nx 2022
Generation
AZ20 (2021–present)
Trim
Standard Trim
Modification
AI Verified Specs
Note

PCD, bore, and stud holes are consistent across 2WD and AWD variants and all trims. Differences are in wheel/tire sizes and offsets. OEM offset range is +35 to +45 mm.

Wheel Specifications

Bolt pattern
5x114.3
Center bore
60.1 mm
Thread size
M14 x 1.5
Torque
140 Nm
Lugs
5
Fastener type
lug bolts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
18x7.519x7.519x820x7.5

Wheel & tire specs guide — Lexus Nx 2022

The 2022 Lexus Nx features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 60.1mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 140 Nm.

PCD, bore, and stud holes are consistent across 2WD and AWD variants and all trims. Differences are in wheel/tire sizes and offsets. OEM offset range is +35 to +45 mm.

From the factory, the Lexus Nx 2022 is offered with OEM tires in the following sizes: 235/60R18, 235/55R18, 235/55R19, 235/50R19, 235/50R20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
