2017 Tesla Model 3 Bolt Pattern 5x114.3

Wheel and tire specifications for the Tesla Model 3 2017. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Tesla Model 3
✨ AI-generated image for reference only

Vehicle Info

Tesla Model 3 2017
Generation
1st Generation (2017–2023)
Trim
Standard Trim
Modification
AI Verified Specs
Note

All trims (RWD, AWD, Performance) share the same PCD, center bore, stud size, and torque. Only wheel and tire sizes/offsets vary.

Wheel Specifications

Bolt pattern
5x114.3
Center bore
64.1 mm
Thread size
M14 x 1.5
Torque
175 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
18x8.519x8.520x9.020x10.0

Wheel & tire specs guide — Tesla Model 3 2017

The 2017 Tesla Model 3 features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 64.1mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 175 Nm.

All trims (RWD, AWD, Performance) share the same PCD, center bore, stud size, and torque. Only wheel and tire sizes/offsets vary.

From the factory, the Tesla Model 3 2017 is offered with OEM tires in the following sizes: 235/45R18, 235/40R19, 235/35R20, 275/30R20. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
