2025 Tesla Model Y Bolt Pattern 5x114.3

Wheel and tire specifications for the Tesla Model Y 2025. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

✨ AI-generated image for reference only

Vehicle Info

Tesla Model Y 2025

Generation

1st Generation (2020–2025)

Trim

Standard Trim

Modification

AI Verified Specs

Note

All trims share the same bolt pattern, center bore, and lug nut specifications. Wheel and tire sizes vary by trim (Standard/Long Range vs Performance) and wheel package.

Wheel Specifications

Bolt pattern

5x114.3

Center bore

64.1 mm

Thread size

M14 x 1.5

Torque

175 Nm

Lugs

Fastener type

lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes

18x8.519x9.520x9.521x9.521x10.5

Wheel & tire specs guide — Tesla Model Y 2025

The 2025 Tesla Model Y features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 64.1mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 175 Nm.

All trims share the same bolt pattern, center bore, and lug nut specifications. Wheel and tire sizes vary by trim (Standard/Long Range vs Performance) and wheel package.

From the factory, the Tesla Model Y 2025 is offered with OEM tires in the following sizes: 235/55R18, 255/45R19, 255/40R20, 255/35R21, 275/35R21. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
