2006 Toyota Rav4 Bolt Pattern 5x114.3

Wheel and tire specifications for the Toyota Rav4 2006. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

✨ AI-generated image for reference only

Vehicle Info

Toyota Rav4 2006

Generation

3rd Generation (2006–2012)

Trim

Standard Trim

Modification

AI Verified Specs

Note

All 2006 RAV4 USDM models (Base, Sport, Limited, 2WD and 4WD) share the same bolt pattern, hub bore, stud size, and number of lugs. Tire and wheel sizes vary by trim and engine.

Wheel Specifications

Bolt pattern

5x114.3

Center bore

60.1 mm

Thread size

M12 x 1.5

Torque

103 Nm

Lugs

Fastener type

lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes

16x6.517x718x7.5

Wheel & tire specs guide — Toyota Rav4 2006

The 2006 Toyota Rav4 features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 60.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 103 Nm.

All 2006 RAV4 USDM models (Base, Sport, Limited, 2WD and 4WD) share the same bolt pattern, hub bore, stud size, and number of lugs. Tire and wheel sizes vary by trim and engine.

From the factory, the Toyota Rav4 2006 is offered with OEM tires in the following sizes: 215/70R16, 225/65R17, 235/65R17, 235/55R18. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
