2015 Toyota Rav4 Bolt Pattern 5x114.3

Wheel and tire specifications for the Toyota Rav4 2015. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Toyota Rav4
✨ AI-generated image for reference only

Vehicle Info

Toyota Rav4 2015
Generation
XA40 Facelift (2015–2019)
Trim
Standard Trim
Modification
AI Verified Specs
Note

2WD and AWD variants share the same PCD, center bore, thread, and torque; they differ primarily in 17" vs 18" wheel/tire packages.

Wheel Specifications

Bolt pattern
5x114.3
Center bore
60.1 mm
Thread size
M12 x 1.5
Torque
103 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
17x6.518x7.5

Wheel & tire specs guide — Toyota Rav4 2015

The 2015 Toyota Rav4 features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 60.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 103 Nm.

2WD and AWD variants share the same PCD, center bore, thread, and torque; they differ primarily in 17" vs 18" wheel/tire packages.

From the factory, the Toyota Rav4 2015 is offered with OEM tires in the following sizes: 225/65R17, 235/55R18. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
