2018 Toyota Rav4 Bolt Pattern 5x114.3

Wheel and tire specifications for the Toyota Rav4 2018. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Toyota Rav4
✨ AI-generated image for reference only

Vehicle Info

Toyota Rav4 2018
Generation
Fourth Generation (XA40) (2013–2018)
Trim
Standard Trim
Modification
AI Verified Specs
Note

Bolt pattern, center bore, thread size, and lug count do not vary by trim or drivetrain (FWD/AWD) for 2018 USDM RAV4. Differences are in tire/wheel sizes and offsets.

Wheel Specifications

Bolt pattern
5x114.3
Center bore
60.1 mm
Thread size
M12 x 1.5
Torque
103 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
17x6.517x718x7.5

Wheel & tire specs guide — Toyota Rav4 2018

The 2018 Toyota Rav4 features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 60.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 103 Nm.

Bolt pattern, center bore, thread size, and lug count do not vary by trim or drivetrain (FWD/AWD) for 2018 USDM RAV4. Differences are in tire/wheel sizes and offsets.

From the factory, the Toyota Rav4 2018 is offered with OEM tires in the following sizes: 225/65R17, 235/55R18. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
