2011 Toyota Sienna Bolt Pattern 5x114.3

Wheel and tire specifications for the Toyota Sienna 2011. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Toyota Sienna
✨ AI-generated image for reference only

Vehicle Info

Toyota Sienna 2011
Generation
XL30 (2011–2017)
Trim
Standard Trim
Modification
AI Verified Specs
Note

All USDM 2011 Siennas share the same PCD, hub bore, thread size, and lug count; wheel and tire sizes differ mainly by engine and trim level (17/18/19" fitments).

Wheel Specifications

Bolt pattern
5x114.3
Center bore
60.1 mm
Thread size
M12 x 1.5
Torque
103 Nm
Lugs
5
Fastener type
lug nuts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
17x6.517x718x719x7

Wheel & tire specs guide — Toyota Sienna 2011

The 2011 Toyota Sienna features a 5x114.3 bolt pattern, meaning it has 5 lug nuts arranged on a 114.3mm diameter circle, the center bore measures 60.1mm, the wheels are secured with M12 x 1.5 threaded lug nuts torqued to 103 Nm.

All USDM 2011 Siennas share the same PCD, hub bore, thread size, and lug count; wheel and tire sizes differ mainly by engine and trim level (17/18/19" fitments).

From the factory, the Toyota Sienna 2011 is offered with OEM tires in the following sizes: 235/60R17, 235/55R18, 235/50R19. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
