2024 Volkswagen Atlas Bolt Pattern 5x112

Wheel and tire specifications for the Volkswagen Atlas 2024. Find the bolt pattern, rim size, center bore and more. Most available tire prices include installation at Avansys Tire Shop, Miami Gardens.

Volkswagen Atlas
✨ AI-generated image for reference only

Vehicle Info

Volkswagen Atlas 2024
Generation
2nd Generation (facelift) (2021–2024)
Trim
Volkswagen Atlas (USDM)
Modification
AI Verified Specs
Note

All trims share the same bolt pattern, hub bore, and fastener type. Differences are mainly in wheel diameter, width, offset, and tire size. No change in bolt pattern or lug count between 2WD and 4Motion AWD models.

Wheel Specifications

Bolt pattern
5x112
Center bore
57.1 mm
Thread size
M14 x 1.5
Torque
120 Nm
Lugs
5
Fastener type
lug bolts

Tire & Wheel Sizes

Tire sizes

Click a size to see available tires.

Rim sizes
7.5Jx178Jx188Jx198Jx209Jx21

Wheel & tire specs guide — Volkswagen Atlas 2024

The 2024 Volkswagen Atlas features a 5x112 bolt pattern, meaning it has 5 lug nuts arranged on a 112mm diameter circle, the center bore measures 57.1mm, the wheels are secured with M14 x 1.5 threaded lug nuts torqued to 120 Nm.

All trims share the same bolt pattern, hub bore, and fastener type. Differences are mainly in wheel diameter, width, offset, and tire size. No change in bolt pattern or lug count between 2WD and 4Motion AWD models.

From the factory, the Volkswagen Atlas 2024 is offered with OEM tires in the following sizes: 245/65R17, 245/60R18, 255/60R18, 255/55R19, 255/50R20, 265/45R21. These sizes determine compatibility when shopping for replacement or upgraded tires and wheels.
